Bimetal Thermometer - 150mm (6") Dial - Adjustable Angle - Stainless Steel

A 150mm (6") adjustable angle bimetal thermometer is a mechanical temperature measurement instrument with an extra-large dial and versatile mounting configuration that uses a coiled bimetallic strip to indicate temperature without requiring external power. This professional thermometer features 304 stainless steel case with IP65 protection, 316 SS NPT connection, 63mm stem length, adjustable angle capability, and 1% accuracy, designed for UAE's industrial facilities, large-scale process plants, and critical monitoring applications across Dubai and the Emirates where maximum visibility, flexible installation positioning, and maintenance-free temperature monitoring are essential.

What is a 150mm adjustable angle bimetal thermometer and when do I need one in the UAE?

The 150mm (6") dial is the largest standard industrial thermometer size, providing maximum visibility from distance in large facilities, outdoor installations, and critical monitoring applications. Adjustable angle design features a swivel connection that allows the dial to be rotated and positioned at any angle for optimal visibility after installation—critical when the process connection location doesn't naturally position the dial for easy reading. Bimetal technology uses two different metals bonded together that expand at different rates when heated, moving a pointer across the dial without batteries, power supply, or electronics. The 304 stainless steel case with IP65 protection resists dust and moisture, while the 316 SS NPT connection provides superior corrosion resistance. When your Dubai facility needs to monitor temperature from across a room, in outdoor installations, or in critical applications where visibility and flexible positioning cannot be compromised, this is the thermometer to specify.

What are the key features of this 150mm adjustable angle bimetal thermometer?

- Extra-Large 6" (150mm) Dial: Maximum visibility for easy reading from distance in UAE facilities
- Adjustable Angle Design: Versatile installation positioning for optimal dial visibility
- Bimetal Sensing Technology: Accurate mechanical measurement without external power required
- 304 Stainless Steel Case: Rugged construction for harsh UAE industrial environments
- 316 SS NPT Connection: Superior corrosion resistance for Emirates' conditions
- IP65 Protection: Complete dust and moisture resistance for Dubai facilities
- 1% Accuracy: Precise and reliable readings for industrial applications
- 63mm Stem Length: Adequate immersion for accurate measurement
- Dual Scale: 0-120°C / 0-250°F for versatile application
- Maintenance-Free: No batteries, no calibration, no power required

What industries and applications use 150mm adjustable angle bimetal thermometers in the UAE?

- Large-scale industrial facilities requiring maximum visibility across UAE
- Process plants and chemical processing with critical temperature monitoring
- Outdoor installations and harsh environments in Dubai
- Pipeline temperature measurement where visibility and positioning are challenging
- HVAC systems in large commercial buildings throughout Emirates
- Oil & gas facilities with distance monitoring requirements
- Manufacturing operations requiring maximum dial visibility with flexible positioning
- Any critical application where temperature must be readable from across a room

Installation Guidelines

Thread NPT connection into process connection (pipe, tank, vessel). Ensure adequate stem immersion for accurate measurement. After installation, rotate dial housing to desired angle for optimal visibility. Tighten adjustment mechanism to lock dial position. No power connection or calibration required—ready to use immediately upon installation.

Technical Specifications

| Specification | Details |
|--------------|---------|
| Dial Size | 150mm (6 inches) - extra large |
| Sensing Technology | Bimetal (mechanical) |
| Case Material | 304 Stainless Steel |
| Connection Material | 316 Stainless Steel |
| Connection Type | 1/2" NPT |
| Mount Type | Adjustable angle (swivel positioning) |
| Stem Length | 63mm |
| Temperature Range | 0-120°C / 0-250°F |
| Accuracy | 1% (high precision) |
| Protection Rating | IP65 (dust and moisture resistant) |
| Power Required | None (mechanical operation) |
| Region | UAE (Dubai, Abu Dhabi, Emirates) |

Perfect for industrial machinery, HVAC systems, pipelines, process plants, and general temperature monitoring requiring maximum visibility and flexible installation angles. Delivers accurate, reliable temperature measurement without power requirements or maintenance complexity in Dubai's most demanding industrial environments.
